Thông số kỹ thuật
| Layer | Unmanaged |
|---|---|
| Switching Capacity | 2 Gbps |
| Packet Forwarding Rate | 1.488 Mpps |
| Description of Function Slots | Port 1-8: 8 × RJ-45 10/100 Mbps (PoE); Port 9-10: 2 × RJ-45 10/100 Mbps (Uplink) |
| Operating Temperature | -10 °C to +55 °C |
| Operating Humidity | 10%–90% (RH), non-condensing |
| Power Supply | External power supply: 53 V, 50/60 Hz, max 1.22 A |
| Power Consumption | Idling: 1.9W; Full load: 63.6W |
| Statics Protection | Air discharge: 8kV; Contact discharge: 6kV |
| Lightning Protection | Common mode: 6kV; Differential mode: 1kV |
| Weight | 0.28kg |
| Dimensions | 184.6 × 77.4 × 27 mm |
| Casing Material | Sheet Metal |
| Installation | Desktop mount; wall mount |
| PoE Power | Port 1-8≤30 W, total≤60 W |
| PoE Protocol | IEEE 802.3af; IEEE 802.3at |
| PoE Pin Assignment | 1,2,4,5 (V+),3,6,7,8 (V-) |
| Long Distance PoE | Yes |
| DIP Switch | Long Distance PoE: The transmission distance of ports 1–8 can reach up to 250 meters. The negotiation speed can be reduced to 10 Mbps. |
| Packet Buffer Size | 768 Kbit |
| Jumbo Frame | 2048 Byte |
| MAC Table Size | 2K |
| Communication Standard | IEEE 802.3; IEEE 802.3u; IEEE 802.3x |
Thông số có thể thay đổi theo lô hàng. Liên hệ Ms Đức 097 3012696 để xác nhận trước khi đặt mua.
