Mô tả
Thông số kỹ thuật
| Chipset | Intel® Z890 Express Chipset |
|---|---|
| CPU | LGA1851 socket: Support for Intel® Core™ Ultra ProcessorsL3 cache varies with CPU |
| Bộ Nhớ | Support for DDR5 9500(O.C) / 9466(O.C) / 9333(O.C) / 9200(O.C)/ 9066(O.C) / 8933(O.C) /8800(O.C) /8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules.4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity)of system memoryDual channel memory architectureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modulesSupport CUDIMM memory module(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” for more information.) |
| Card Màn Hình Tích Hợp | Integrated Graphics Processor-Intel® HD Graphics support:– 2 x Intel® Thunderbolt™ 4 connectors (USB4® USB Type-C® ports), supporting DisplayPort and Thunderbolt™ video outputsWhen a Thunderbolt™ monitor is installed, the maximum resolution supported is 5120×2880@60 Hz with 24 bpp (single display output).When a USB4® USB Type-C® monitor is installed, the maximum resolution supported is 3840×2160@240 Hz (single display output).* Because of the limited I/O resources of the PC architecture, the number of Thunderbolt™devices that can be used is dependent on the number of the PCI Express devices beinginstalled. (Refer to Chapter 2-6, “Back Panel Connectors,” for more information.)* Support for DisplayPort 2.1 version and HDCP 2.3– 1 x Front HDMI port, supporting a maximum resolution of 1920×1080@30 Hz* Support for HDMI 1.4 version(Graphics specifications may vary depending on CPU support.)Support for up to triple-display at the same time |
| Âm Thanh | ESS ES9280 chip (rear panel audio)– Support for DTS:X® Ultra– High Definition Audio– 2-channelESS ES9118 DAC chip (front panel audio) |
| LAN | 2 x Marvell® AQtion AQC113C 10GbE LAN chips (10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication module | Intel® Wi-Fi 7 BE200NGW– 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands– BLUETOOTH 5.4– Support for 11be 320MHz wireless standard(Actual data rate may vary depending on environment and equipment.) |
| Khe Cắm Mở Rộng | CPU:– 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.– 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x8 (PCIEX8)Chipset:– 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) |
| Lưu Trữ | CPU:– 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU)– 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU)Chipset:– 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)– 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)– 4 x SATA 6Gb/s connectorsRAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devicesRAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
| USB | CPU:– 2 x Intel® Thunderbolt™ 4 (USB Type-C®) ports on the back panel*Support up to 40Gbps with Thunderbolt devices*Support up to 20Gbps with USB4 devices*Support up to 10Gbps with USB 3.2 devicesChipset:– 6 x USB 3.2 Gen 2 Type-A ports (red) on the back panelChipset+USB 3.2 Gen 2×2 Hub:– 1 x USB Type-C® port with USB 3.2 Gen 2×2 support, available through the internal USB headerChipset+USB 3.2 Gen 2 Hub:– 4 x USB 3.2 Gen 2 Type-A ports (red) on the back panelChipset+USB 3.2 Gen 1 Hub:– 4 x USB 3.2 Gen 1 ports available through the internal USB headersChipset+USB 2.0 Hub:– 4 x USB 2.0/1.1 ports available through the internal USB headers |
| Đầu Nối I/O Bên Trong | 1 x 24-pin ATX main power connector2 x 8-pin ATX 12V power connectors1 x CPU fan header1 x CPU fan/water cooling pump header4 x system fan headers4 x system fan/water cooling pump headers4 x addressable RGB Gen2 LED strip headers1 x RGB LED strip header4 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB Type-C® header, with USB 3.2 Gen 2×2 support2 x USB 3.2 Gen 1 headers2 x USB 2.0/1.1 headers1 x noise detection header1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)1 x HDMI port (Note)1 x power button1 x reset button1 x reset jumper1 x Clear CMOS jumper2 x temperature sensor headersVoltage Measurement Points |
| Cổng Kết Nối Sau | 1 x Q-Flash Plus button1 x Clear CMOS button2 x Intel® Thunderbolt™ 4 connectors (USB Type-C® ports)10 x USB 3.2 Gen 2 Type-A ports (red)2 x RJ-45 ports2 x antenna connectors (2T2R)2 x audio jacks |
| Bộ Điều Khiển I/O | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage detectionTemperature detectionFan speed detectionWater cooling flow rate detectionFan fail warningFan speed control |
| Wireless Lan & Bluetooth | Intel® Wi-Fi 7The Wireless module is pre-installed in the M.2 (Key-E) slotSupports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8GbpsSupports 802.11 a/ b/ g/ n/ ac/ ax/ beSupports Bluetooth® 5.4**, MLO, 4KQAM |
| BIOS | 1 x 256 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | Support for GIGABYTE Control Center (GCC)* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.Support for Q-FlashSupport for Q-Flash PlusSupport for Smart Backup |
| Bundled Software | Norton® Internet Security (OEM version)LAN bandwidth management software |
| Hệ Điều Hành | Support for Windows 11 64-bit |
| PCB INFO | E-ATX Form Factor; 30.5cm x 28.5cm |
Thông số có thể thay đổi theo lô hàng. Liên hệ Ms Đức 097 3012696 để xác nhận trước khi đặt mua.
