Mô tả
Thông số kỹ thuật
| CPU hỗ trợ | Support Intel Core Ultra Processors (Series 2) , LGA1851Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
|---|---|
| Chipset | Intel Z890 Chipset |
| RAM hỗ trợ | 4 x DIMM slots, max. 192GB, DDR5Support up to 9066+MT/s (OC), Non-ECC, Un-buffered, Clocked Unbuffered DIMM (CUDIMM)*Dual Channel Memory ArchitectureDIMM FitSupports Intel® Extreme Memory Profile (XMP) memory moduleASUS Enhanced Memory Profile III(AEMPIII) |
| Khe cắm mở rộng | Intel Core Ultra Processors(Series 2)1 x PCIe 5.0 x16 slot Intel Z890 Chipset1 x PCIe 4.0 x16 slot (supports x4 mode)1 x PCIe 4.0 x4 slot2 x PCIe 4.0 x1 slots |
| Ổ cứng hỗ trợ | Total Supports 4 x M.2 slots and 4 x SATA 6Gb/s portsIntel Core Ultra Processors(Series 2)M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) Intel Z890 ChipsetM.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes) 4 x SATA 6Gb/s ports |
| Cổng kết nối (Internal) | Fan and Cooling Related1 x 4-pin CPU Fan header1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header4 x 4-pin Chassis Fan headersPower Related1 x 24-pin Main Power connector2 x 8-pin +12V CPU Power connectorStorage Related4 x M.2 slots (Key M)4 x SATA 6Gb/s portsUSB1 x USB 20Gbps connector (supports USB Type-C® )1 x USB 5Gbps header supports 2 additional USB 5Gbps ports2 x USB 2.0 headers support 4 additional USB 2.0 portsMiscellaneous3 x Addressable Gen 2 headers1 x Clear CMOS header1 x Chassis Intrusion header1 x COM Port header1 x Front Panel Audio header (F_AUDIO)1 x 10-1 pin Front System Panel header1 x Thunderbolt™ (USB4®) header |
| Cổng kết nối (Back Panel) | 1 x Thunderbolt 4 USB Type-C port1 x USB 20Gbps port (1 x USB Type-C with DP Alt mode)3 x USB 10Gbps ports (3 x Type-A)3 x USB 5Gbps ports (3 x Type-A)1 x DisplayPort1 x HDMI port1 x Wi-Fi module1 x Intel 2.5Gb Ethernet port5 x Audio jacks1 x Optical S/PDIF out port1 x BIOS FlashBack™ button |
| LAN / Wireless | LAN 1 x Intel 2.5Gb Ethernet TUF LANGuard Wireless Intel Wi-Fi 7 2×2 Wi-Fi 7 (802.11be) Supports 2.4/5/6GHz frequency band Support Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate. Bluetooth v5.4 |
| Kích cỡ | ATX Form Factor12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
Thông số có thể thay đổi theo lô hàng. Liên hệ Ms Đức 097 3012696 để xác nhận trước khi đặt mua.
